6GHz, TE MATE-AX TO TE FAKRA-Z WITH RTK031 Cable Assembly
The MATE-AX to FAKRA with RTK031 CABLE is a miniaturized, high-performance hybrid coaxial cable assembly designed for demanding automotive applications like ADAS cameras, sensors, V2X, and infotainment systems. It features a compact, space-saving MATE-AX connector on one end for high-density integration, and a standard FAKRA connector (often female Code Z) on the other end for backward compatibility, interconnected by robust RTK031 automotive-grade coaxial cable. Supporting frequencies up to 6 GHz (with optimized designs reaching 15 GHz), it delivers reliable 50 Ω signal transmission with low loss, high EMI immunity, and mechanical durability (withstanding ≥100N retention force, -40°C to +105°C temperatures), while offering significant space (up to 75%) and weight (34%) savings compared to traditional FAKRA solutions, meeting key automotive standards like LV 214/USCAR.
